Specifications

• Actual Mounting Flange
  4 Bolt Std: 44.4 [1.75] Dia. X 3.0 [.12] Pilot, .375-16 Mounting
• Actual Output Shaft
  25.4 [1.00] Dia. Straight With Woodruff Key And 1/4-20 Threaded Hole
• Actual Port Type
  .875-14 Unf-2B O-ring Port, Size 10 Accepts Fittings For Sae J1926
• Case Drain
  No Case Drain
• Continuous Flow Rate
  15 gpm
• Continuous Pressure
  1350 psi
• Continuous Torque
  3110 in
• Displacement
  17.90 in³/r
• Inlet and Outlet Port Size
  Straight Thread O-ring SAE 7/8-14 UNF-2B Ports Size 10
• Intermittent Flow Rate
  20 gpm
• Intermittent Pressure
  1800 psi
• Intermittent Torque
  4121 in
• Max Continuous Oil Viscosity
  100 Saybold universal second
• Max Operating Temperature
  180 °F
• Maximum RPM-Continuous
  969 rpm
• Max System Operating Temperature
  -34°C to 82 °C
• Motor Port Size
  7/8–14 UNF-2B
• Motor Port Type
  Straight Thread O-Ring SAE
• Mounting Type
  4-Bolt Flange - 1.75 in Pilot
• Output Shaft Size
  1 in Straight - Woodruff Key
• Overall Height
  3.87 in
• Overall Length
  7.79 in
• Overall Width
  3.31 in
• Port Configuration
  .875-14 UNF-2B SAE O-Ring Ports
• Recommended Filtration
  Per Iso Cleanliness Code. Level 18/13
• Recommended Fluids
  Premium Quality, Anti-Wear Type Hydraulic Oil with A Viscosity Of Not Less Than 701 Sus or 13Cst with Best Range Of 100 - 200 Sus or 20 - 43 Cst At Operating Temperature,
• Repair Manual#
  7-117
• Repair Parts Drawing#
  6-121
• Replacement Bearing Race
  007, 008 & 009 Design - 7462-000
• Replacement Buna Seal Kit
  007 Design - 60023-000, 008 & 009 Design - 60540-000
• Replacement Drive - Sold Separately
  009 Design - 22253-000
• Replacement Geroler - Sold Separately
  7
• Replacement Gerotor Sold Seprately
  009 Design - 8277-026
• Replacement Long Cap Screw Cap End
  009 Design - 16294-288 - 7 Required
• Replacement Mounting Flange
  009 & 008 Design 22000-002, 007 Design 7464-000
• Replacement Needle Thrust Bearing
  007, 008 & 009 Design - 7537-000
• Replacement Output Shaft
  007, 008 & 009 Design - 7360-001
• Replacement Rear Housing
  009 Design - 22230-001, 008 & 007 Design - 7359-001
• Replacement Short Cap Screw Mnt End
  007, 008 & 009 Design - 16292-088 - 4 Required
• Replacement Viton Seal Kit
  007 Design - 60032-000, 008 & 009 Design - 60544-000
• Seal Type
  Standard
• Series
  H-Series
• Shaft Type
  Straight
• Weight
  13.86, 14.0 lbs
