Overview
Mfr description
EST2-1-43-K26 ACCUM CH W/FS HOLE 5M ELIT
- Elite accumulation chains have external rollers on both sides, which match with the teeth on the chain-wheel on one side, and on the other side to support the chain in the profile.
- Specially made bushings help prevent contact corrosion between the inner link and outer plate.
- All chains are treated with a special chain lubricant that adheres well within the temperature range of -5 degrees C to 150 degrees C.
Specifications
- SeriesAccumulation
- Chain Size & PitchEST2-1-43-K26 / 3/4 in
- Chain ConstructionAccumulation Chains
- Number Of Strands Across1
- Overall Length5.00 m
- Link Plate Height16.13 mm
- Link Plate Thickness1.85 mm
- Pin Diameter5.72 mm
- Pin Length43.00 mm
- Roller Diameter12.07 mm
- Chain Number & PitchEST2-1-43-K26 / 3/4 in
- Roller Width11.68 mm
- Manufacturer Catalog
- Weight38.00 lbs
- Manufacturer Upc Number847648610044
- UPC_NO847648610044
- 2D Drawings
- Pitch3/4 in
- Product TypeRoller Chain
